I wanted a very small arduino type chip and foud out about a soic version of the attiny85v. My aim is a chip with a pull-up resistor to the reset pin. so a internal clock on 8Mhz. the fuse settings reflect this. here is my attempt at a altered hardware folder for the arduino ide. of course you cannot use the normal upload procedure and have to use icsp to program the chip because the attiny does not have a hardware UART.
unfortunately i have had no time yet to test the files, but here is wat i deduced by looking at the original atmega168 pdf and the pins_arduino.c and pins_arduino.h files and a very good explanation of the workings from here:
http://www.urbanhonking.com/ideasfordozens/2009/05/an_tour_of_the_arduino_interna.html
So this is the changed pins_arduino.c file:
/*
pins_arduino.c - pin definitions for the Arduino board
Part of Arduino / Wiring Lite
Copyright (c) 2005 David A. Mellis
This library is free software; you can redistribute it and/or
modify it under the terms of the GNU Lesser General Public
License as published by the Free Software Foundation; either
version 2.1 of the License, or (at your option) any later version.
This library is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
Lesser General Public License for more details.
You should have received a copy of the GNU Lesser General
Public License along with this library; if not, write to the
Free Software Foundation, Inc., 59 Temple Place, Suite 330,
Boston, MA 02111-1307 USA
$Id: pins_arduino.c 254 2007-04-20 23:17:38Z mellis $
adapted to ATTiny85 2010-05-25 22:19:10 by swc
*/
#include <avr/io.h>
#include "wiring_private.h"
#include "pins_arduino.h"
// On the Sanguino board, digital pins are also used
// for the analog output (software PWM). Analog input
// pins are a separate set.
// ATMEL ATTINY85
//
// +-\/-+
// PB5 1| |8 VCC
// (AI 3) PB3 2| |7 PB2 (AI 1)
// (AI 2) PB4 3| |6 PB1 PWM
// GND 4| |5 PB0 PWM
// +----+
#define PB 1
// these arrays map port names (e.g. port B) to the
// appropriate addresses for various functions (e.g. reading
// and writing)
const uint8_t PROGMEM port_to_mode_PGM[] =
{
NOT_A_PORT,
&DDRB,
};
const uint8_t PROGMEM port_to_output_PGM[] =
{
NOT_A_PORT,
&PORTB,
};
const uint8_t PROGMEM port_to_input_PGM[] =
{
NOT_A_PORT,
&PINB,
};
const uint8_t PROGMEM digital_pin_to_port_PGM[] =
{
PB, /* 0 */
PB,
PB,
PB,
PB,
};
const uint8_t PROGMEM digital_pin_to_bit_mask_PGM[] =
{
_BV(0), /* 0, port B */
_BV(1),
_BV(2),
_BV(3),
_BV(4),
};
const uint8_t PROGMEM digital_pin_to_timer_PGM[] =
{
TIMER0A, /* 0 - PB0 */
TIMER1A, /* 1 - PB1 */
NOT_ON_TIMER, /* 2 - PB2 */
TIMER1B, /* 3 - PB3 */
TIMER1B, /* 4 - PB4 */
};
and this the boards.txt file
##############################################################
attiny85.name=attiny85
attiny85.upload.using=avrispmk2
attiny85.upload.maximum_size=8190
attiny85.upload.speed=38400
attiny85.bootloader.low_fuses=0xE2
attiny85.bootloader.high_fuses=0xDF
attiny85.bootloader.extended_fuses=0xFF
attiny85.bootloader.path=attiny85v
attiny85.bootloader.file=attiny85v
attiny85.bootloader.unlock_bits=0x3F
attiny85.bootloader.lock_bits=0x0F
attiny85.build.mcu=attiny85v
attiny85.build.f_cpu=8000000L
attiny85.build.core=arduino
of course i should make one for the attiny13 as well
I have not done the analog mapping in wiring_analog.c yet. first i have to find out how that works. same with pwm. maybe the attiny2313 port wil clarify it.
remember, this code is not tested yet, but pure to see if I missed something. i encourage everybody to post comments and improve on this.
*update added attiny85.upload.using=avrispmk2
to the boards.txt file. and removed attiny85.upload.protocol=stk500
