1  Using Arduino / Project Guidance / Re: Trying to see if my idea is able to be realized, or if I am just dreaming. on: May 19, 2013, 12:42:06 pm
Moderator edit:  Pointless personal denigration deleted.

2  Using Arduino / Project Guidance / Re: Trying to see if my idea is able to be realized, or if I am just dreaming. on: May 19, 2013, 12:38:18 am
That sounds like a great idea! Those extra arms would definitely come in handy doing simple tasks such as holding a flashlight or a wrench in place. The EEG (or voice commands) could active the arms/tool, and an eye tracking rig (http://hackaday.com/2012/05/30/opencv-knows-where-youre-looking-with-eye-tracking/) and glyphs could be used for aiming. Obviously this is a complex project involving many smaller sub-systems, so expect to do a lot of prototyping. Arduino/Rasberry Pi should have all the computing power you need, and are fortunately very cheap. I can see hardware becoming the expensive part here, as good actuators and batteries are relatively expensive. Go for proof of concept at this point with lightweight/weak arms, then build up to the full backpack.

Good luck. Just dont let them get the better of you, okay?

3  Using Arduino / Project Guidance / Re: How to reduce electrical noise from motorcycle alternator? on: May 19, 2013, 12:07:34 am
Oh, and unfortunately I wont actually be able to try any troubleshooting on this for a while as I am moving cross country and the engine is broken again smiley-sad

Once I have the engine fixed I may be able to run the bike without the alternator attached, which would eliminate that as the source of the noise. If the noise is still present with the alternator disconnected, my next guess would be the ignition coils/spark plugs. We'll have to wait and see...
4  Using Arduino / Project Guidance / How to reduce electrical noise from motorcycle alternator? on: May 19, 2013, 12:05:08 am
I've been working on adding custom brake and turn signal controls to my motorcycle seen here
http://forum.arduino.cc/index.php/topic,57812.0.html
http://forum.arduino.cc/index.php?topic=62948.msg1121047#msg1121047
http://forum.arduino.cc/index.php?topic=149254.msg1121061#msg1121061

My code and circuit worked great when wired into the motorcycle battery. Then when I actually finished the motorcycle engine and ran it, my lights went haywire! When the engine is off, the lights work fine; engine on and they blink rapidly. Turn the engine off and they work normal again.

What I imagine is happening is that some dirty electrical frequency is getting into my Arduino inputs and telling the Arduino that the buttons have been pushed when they actually haven't. I'm thinking I'll have to add ferrite beads or possibly capacitors somehow?

The full electrical schematic is attached as a Fritzing file. Thanks!
5  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (???) on: May 05, 2013, 10:11:13 pm
Thanks for all your help DuaneB! I am not finished with the project this code was being used for and came here to post the resolution, but I see you've beat me to it.
6  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (???) on: March 21, 2013, 04:07:40 pm
Okay, so not actually solved. Next step is to get it working on a mutli-interrupt sketch. Stand by.
7  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (??????) on: March 20, 2013, 05:01:10 pm
For redundancy and for the next person who has this problem, I'll summarize the problem and solution here.

The problem was that interrupts are not assigned to the same pins across different boards.  (See http://arduino.cc/en/Reference/AttachInterrupt).  By changing
Code:
attachInterrupt(THROTTLE_SIGNAL_IN,calcInput,CHANGE);
to
Code:
attachInterrupt(INT1,calcInput,CHANGE);
we are able to properly assign pins. This let the data start flowing.

Another mistake I made was that I forgot to ground the Arduino board to the RC receiver, so at first when Serial.println was successful, I was only getting gibberish.

This sketch now works on the Arduino Micro. Many thanks to Duane B for the assist; my PowerWheels beer cooler should be up and running in no time.
8  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (??????) on: March 19, 2013, 08:58:17 am
Great, I was really hoping you'd see this! I'll head over to your blog.
9  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (??????) on: March 18, 2013, 05:22:38 pm
The only bit of code I've changed is to add a few "if" and "analogWrite()" functions down near line 145, and to remove all reference to steering since I wont be using it.

Code:
// MultiChannels
//
// rcarduino.blogspot.com
//
// A simple approach for reading three RC Channels using pin change interrupts
//
// See related posts -
// http://rcarduino.blogspot.co.uk/2012/01/how-to-read-rc-receiver-with.html
// http://rcarduino.blogspot.co.uk/2012/03/need-more-interrupts-to-read-more.html
// http://rcarduino.blogspot.co.uk/2012/01/can-i-control-more-than-x-servos-with.html
//
// rcarduino.blogspot.com
//

// include the pinchangeint library - see the links in the related topics section above for details
#include <PinChangeInt.h>

#include <Servo.h>


// Assign your channel in pins
#define THROTTLE_IN_PIN 2
#define AUX_IN_PIN 3
const int MOTORFWD = 5;
const int MOTORRVS = 6;
const int HORN = 10;
int Throttle = 0;


// Assign your channel out pins
#define THROTTLE_OUT_PIN 4
#define AUX_OUT_PIN 7

// Servo objects generate the signals expected by Electronic Speed Controllers and Servos
// We will use the objects to output the signals we read in
// this example code provides a straight pass through of the signal with no custom processing
Servo servoThrottle;
Servo servoAux;

// These bit flags are set in bUpdateFlagsShared to indicate which
// channels have new signals
#define THROTTLE_FLAG 8
#define AUX_FLAG 9

// holds the update flags defined above
volatile uint8_t bUpdateFlagsShared;

// shared variables are updated by the ISR and read by loop.
// In loop we immediatley take local copies so that the ISR can keep ownership of the
// shared ones. To access these in loop
// we first turn interrupts off with noInterrupts
// we take a copy to use in loop and the turn interrupts back on
// as quickly as possible, this ensures that we are always able to receive new signals
volatile uint16_t unThrottleInShared;
volatile uint16_t unAuxInShared;

// These are used to record the rising edge of a pulse in the calcInput functions
// They do not need to be volatile as they are only used in the ISR. If we wanted
// to refer to these in loop and the ISR then they would need to be declared volatile
uint32_t ulThrottleStart;
uint32_t ulAuxStart;

void setup()
{
  pinMode(MOTORFWD, OUTPUT);
  pinMode(MOTORRVS, OUTPUT);
  pinMode(HORN, OUTPUT);
  Serial.begin(9600);
  while (!Serial)
  {
    ;
  }
  // attach servo objects, these will generate the correct
  // pulses for driving Electronic speed controllers, servos or other devices
  // designed to interface directly with RC Receivers
  servoThrottle.attach(THROTTLE_OUT_PIN);
  servoAux.attach(AUX_OUT_PIN);

  // using the PinChangeInt library, attach the interrupts
  // used to read the channels
  PCintPort::attachInterrupt(THROTTLE_IN_PIN, calcThrottle,CHANGE);
  PCintPort::attachInterrupt(AUX_IN_PIN, calcAux,CHANGE);

}

void loop()
{
  // create local variables to hold a local copies of the channel inputs
  // these are declared static so that thier values will be retained
  // between calls to loop.
  static uint16_t unThrottleIn;
  static uint16_t unAuxIn;
  // local copy of update flags
  static uint8_t bUpdateFlags;

  // check shared update flags to see if any channels have a new signal
  if(bUpdateFlagsShared)
  {
    noInterrupts(); // turn interrupts off quickly while we take local copies of the shared variables

    // take a local copy of which channels were updated in case we need to use this in the rest of loop
    bUpdateFlags = bUpdateFlagsShared;

    // in the current code, the shared values are always populated
    // so we could copy them without testing the flags
    // however in the future this could change, so lets
    // only copy when the flags tell us we can.

    if(bUpdateFlags & THROTTLE_FLAG)
    {
      unThrottleIn = unThrottleInShared;
    }

    if(bUpdateFlags & AUX_FLAG)
    {
      unAuxIn = unAuxInShared;
    }

    // clear shared copy of updated flags as we have already taken the updates
    // we still have a local copy if we need to use it in bUpdateFlags
    bUpdateFlagsShared = 0;

    interrupts(); // we have local copies of the inputs, so now we can turn interrupts back on
    // as soon as interrupts are back on, we can no longer use the shared copies, the interrupt
    // service routines own these and could update them at any time. During the update, the
    // shared copies may contain junk. Luckily we have our local copies to work with :-)
  }

  // do any processing from here onwards
  // only use the local values unAuxIn, unThrottleIn and unSteeringIn, the shared
  // variables unAuxInShared, unThrottleInShared, unSteeringInShared are always owned by
  // the interrupt routines and should not be used in loop

  // the following code provides simple pass through
  // this is a good initial test, the Arduino will pass through
  // receiver input as if the Arduino is not there.
  // This should be used to confirm the circuit and power
  // before attempting any custom processing in a project.

  // we are checking to see if the channel value has changed, this is indicated
  // by the flags. For the simple pass through we don't really need this check,
  // but for a more complex project where a new signal requires significant processing
  // this allows us to only calculate new values when we have new inputs, rather than
  // on every cycle.
Serial.println(Throttle);
  if(bUpdateFlags & THROTTLE_FLAG)
  {
    if(servoThrottle.readMicroseconds() != unThrottleIn)
    {
      servoThrottle.writeMicroseconds(unThrottleIn);
     if ((unThrottleIn < 1665) && (unThrottleIn > 1365))
      {
        Throttle = 0;
        analogWrite (MOTORFWD, Throttle);
        analogWrite (MOTORRVS, Throttle);
       }
         else if(unThrottleIn > 1665)
         {
           Throttle = (unThrottleIn - 1665);
          analogWrite(MOTORFWD, Throttle);
          analogWrite(MOTORRVS, 0);
         }
         else if (unThrottleIn < 1365)
         {
           Throttle = (1365 - unThrottleIn);
            analogWrite(MOTORFWD, 0);
            analogWrite(MOTORRVS, Throttle);
         }
          }
  }

  if(bUpdateFlags & AUX_FLAG)
  {
    if(servoAux.readMicroseconds() != unAuxIn)
    {
      servoAux.writeMicroseconds(unAuxIn);
     /* if (unAuxIn < 1500)
      {
      digitalWrite (HORN, LOW);
      }
      else if (unAuxIn > 1500)
      {
      digitalWrite (HORN, HIGH);
      }
     Serial.println(unAuxIn);*/
    }
  }

  bUpdateFlags = 0;
}


// simple interrupt service routine
void calcThrottle()
{
  // if the pin is high, its a rising edge of the signal pulse, so lets record its value
  if(digitalRead(THROTTLE_IN_PIN) == HIGH)
  {
    ulThrottleStart = micros();
  }
  else
  {
    // else it must be a falling edge, so lets get the time and subtract the time of the rising edge
    // this gives use the time between the rising and falling edges i.e. the pulse duration.
    unThrottleInShared = (uint16_t)(micros() - ulThrottleStart);
    // use set the throttle flag to indicate that a new throttle signal has been received
    bUpdateFlagsShared |= THROTTLE_FLAG;
  }
}

void calcAux()
{
  if(digitalRead(AUX_IN_PIN) == HIGH)
  {
    ulAuxStart = micros();
  }
  else
  {
    unAuxInShared = (uint16_t)(micros() - ulAuxStart);
    bUpdateFlagsShared |= AUX_FLAG;
  }
}
10  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (??????) on: March 17, 2013, 08:49:26 pm
I think the new Micro board like the Leonard board (based on same chip) have to utilize an additional if test before performing serial commands. I think the key new command is this one:

http://arduino.cc/en/Serial/IfSerial


Lefty

Thanks Lefty, I've tried that. Adding that returns all zeros instead of just nothing. So, something changes, but frustratingly I cant tell if it fix anything. And it does nothing for the other symptom of the problem, which is that no PWM instruction is being sent to the OUTPUT pin. Because no good signal is being sent to either the Serial port or the OUTPUT pin, I'm thinking the problem is upstream somewhere...
11  Using Arduino / Motors, Mechanics, and Power / Re: "How To Read Multiple RC Channels" not working on Arduino Micro (??????) on: March 17, 2013, 08:18:19 pm
Just double checked myself in case I had a brain-fart, but nope: Exact same code uploaded to a Duemilanove and pins attached to the same jumper wires and it works perfect. Full control of servos and Serial.println() works just fine.

Is there something that I have to account for on the Micro since it shares USB comms and sketch processing on the same chip? Maybe something to do with the fact that it doesn't reset when the Serial Monitor window is opened?
12  Using Arduino / Motors, Mechanics, and Power / "How To Read Multiple RC Channels" not working on Arduino Micro (???) on: March 17, 2013, 03:19:43 pm
I have been able to successfully use the information seen here http://rcarduino.blogspot.com/2012/04/how-to-read-multiple-rc-channels-draft.html to tap into RC signals to control components. Well, successful on Arduino Duemilanove and Mini, I should say. Not so much on the Arduino Micro.

With the other two boards, I was able to drop in a "Serial.println();" where I needed to get information I wanted. On the Micro, this does not work. By ignoring the below chunk of the code from "void Setup()" I am able to send a test signal back through serial...

Code:
 PCintPort::attachInterrupt(THROTTLE_IN_PIN, calcThrottle,CHANGE);
  PCintPort::attachInterrupt(STEERING_IN_PIN, calcSteering,CHANGE);
  PCintPort::attachInterrupt(AUX_IN_PIN, calcAux,CHANGE);

...but no actual data from the pins.

I tried removing all Serial instructions to see if that was causing problems, but still no signal is getting back out to the components either.

Any ideas on what the problem might be? Thanks all!
13  Using Arduino / General Electronics / Re: *Solved* Voltage Regulators wasting too much power, or "Ouch! Dang that's hot!" on: February 18, 2013, 03:36:10 pm
Yes, you did say 20W+, but poor ol' Radio Shack has crap selection. I'll upgrade before going for final installation.

These are the LEDs I'm using: http://www.ledssuperbright.com/3w-led-c-11/3w-high-power-led-aluminum-wide-angle-module-p-218

They have that little inline transformer there that takes 12v and steps it down to 4v, but it also negates PWM control of the speed that I need. The website says that removing the tranformer lets the LED run at 4v, so that's what I did. The aluminum housing keeps the LEDs plenty cool; I've run then for longer periods of time with no noticeable warmth (The brake/running light will be on whenever the bike is on, but dimmed until the brake is used)
14  Using Arduino / General Electronics / Re: Voltage Regulators wasting too much power, or "Ouch! Dang that's hot!" on: February 18, 2013, 03:01:22 pm
Alright, Fungus, I followed your advice and it worked! (as math should)

I replaced the voltage regulator with a 10ohm, 10W ceramic resistor (http://www.radioshack.com/product/index.jsp?productId=12566075), and it works beautifully! With a supply of 12v, the circuit now draws 0.8A, with about 4v across the LED. The LED is just as bright as ever. The resistor does get very hot though (165*F).
The new circuit:

The middle and bottom LED can share a resistor because only one can be on at a time (they are the blinkers, and there is no "Hazard" dual flash setting)


Also, I realized that I was having a major bonehead moment when measuring the voltage across my regulators as stated in my first post: I was measuring Output to Input, instead of Output to Ground (d'oh!)

Thanks for the help! As usual, I should remember to K.I.S.S.!
15  Using Arduino / General Electronics / Re: Voltage Regulators wasting too much power, or "Ouch! Dang that's hot!" on: February 15, 2013, 11:16:31 pm
Don't forget heatsinks.

Got 'em on there already. That was my first move, but then when I started looking into putting together a thermostat circuit to switch on a fan to help cool the heatsinks, I realized I was going down the wrong path and that what I needed was to solve the problem, not the symptoms. Kind of had to slap myself back on track there.

I'll let you all know how this goes, thanks for setting me straight!
