Topic: NMEA 2000 Shield (Read 22 times) previous topic - next topic

hobi

@allen652: I also look to broadcast information to a Triton T41 MFD.

I have been crawling on the web to find out some raw binary file, that I could use to check my code but no luck.
Therefore, what I have is the NMEA decoder ( Good that this was made open, really a huge piece of work)  that will help me to understand what the Triton sends out initially when powered up, but I will have to reverse the decoder, and assemble some PGNs ( like boat COG , wind direction) and send that to the Triton.

It would be of great help if you could accept to share the piece of SW you did to boradcast PGNs... Please.

What I am concerned about is the address claim, and also device capabilities / ISO aCK stuff.

Thanks in advance.


jpjcb66

#31
Oct 09, 2014, 12:36 pm Last Edit: Oct 09, 2014, 04:41 pm by jpjcb66 Reason: 1
Hello everyone,
I have trouble with PGN 127489 + MFDe7 Raymarine and I have not response from "allen652" .
Can not display engine temperature water.
Can someone please help me?
thank you
jp

allen652

#32
Oct 09, 2014, 04:32 pm Last Edit: Oct 23, 2014, 10:04 am by allen652
I am using an arduino MEGA and the MCP2515 library as mentioned and worked on by coryjfowler https://github.com/coryjfowler/MCP2515_lib.

I built my own shield for a few dollars by purchasing the components from digikey.com. The design is based on seeedstudio's canbus http://www.seeedstudio.com/wiki/images/7/78/CAN-BUS_Shield_v0.9b.pdf.

IC CAN Transceiver: MCP2551-I/P-ND
IC CAN Controller: MCP2515-I/P-ND
16 MHZ Crystal: XC1748-ND
Resistors: 10kohm & 4.7kohm
Capacitors: (2) 22pf & (2) 100nf

I am using non-certified NMEA2000 cabling products that I had manufactured for my current project. I have several available for sale below if interested. See images.
2 meter cable (Male to Female) - $7.5 each
T adapter - $7 each
Male rear panel mount connector - $5 each

I'll put some sample code in my next post.

allen652

Code: [Select]

#include <mcp_can.h>
#include <SPI.h>

MCP_CAN CAN0(53);                                      // Set CS to pin 53
//MCP_CAN CAN0(2); //for my new prototype shield
unsigned char stmp[8] = {0, 0xA0, 0x41, 0, 0, 0, 0, 0};
unsigned char extpgn[26] = {0, 0xA0, 0x41, 0, 0, 0, 0, 0};
void setup(){
  Serial.begin(115200);
  // init can bus, baudrate: 250k
  if(CAN0.begin(CAN_250KBPS) == CAN_OK) Serial.print("can init ok!!\r\n");
  else Serial.print("Can init fail!!\r\n");
  //testPGN127489();
  //transmitPGN127489(0,55.5,164,171,13.54,15.8,221,11.2,32.1,38,44,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0);
  testRPM();
}

void loop(){
  //PGN 127488 binary 011111001000000000
  //for id try 110 + above + 00000000 = 11001111100100000000000000000 = hex 19F20000
  //highest priority = 000 try 00001111100100000000000000000 = hex 1F20000 = dec 32636928

  //PGN 127489 binary 011111001000000001
  //for id try 00001111100100000000100000000 = hex 1F20100 = dec 32637184

  // send data:  id = 0x00, extended frame, data len = 8, stmp: data buf
  CAN0.sendMsgBuf(32636928L, 1, 8, stmp);

  //testPGN127489();
  //transmitPGN127489(0,55.5,164,171,13.54,15.8,221,11.2,32.1,38,44,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0);  //with checkEngine flag set to true
  transmitPGN127489(0,55.5,164,171,13.54,15.8,221,11.2,32.1,38,44,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0);  //with checkEngine flag set to false

  delay(1000);
}
void testPGN127489(){
  //if an engine parameter is not available, set it to 255
  unsigned char extpgn[26] = {0, 208, 14, 170, 13, 151, 136, 236, 4, 37, 2, 112, 207, 11, 0, 255, 255, 255, 255, 1, 0, 0, 0, 0, 255, 255};  //decimal values
  unsigned char temp[8] = {0,0,0,0,0,0,0,0};
  //

  int cur=0;
  for(int i = 0; i<=3; i++){
      temp[0] = i; //frame counter
      if (i==0){
          temp[1] = 26; //total bytes in fast packet
          //send the first 6 bytes
          for(int j = 2; j<8; j++){
               temp[j]=extpgn[cur];
               cur++;
           }
      } else{
           for(int j = 1; j<8; j++){
               temp[j]=255;
           }
           //send the next 7 data bytes
           for(int j = 1; j<8; j++){
               temp[j]=extpgn[cur];
               cur++;
           }
      }
      CAN0.sendMsgBuf(32637184L, 1, 8, temp);
      delay(1);
  }
}
void testRPM(){
  unsigned char stmp[8] = {0, 0xA0, 0x41, 0, 0, 0, 0, 0};
  int rpm;
  for(int i = 0; i<=4200; i=i+100){
      rpm=(i*4);
      stmp[2]=rpm/256;
      stmp[1]=rpm-(stmp[2]*256);
      CAN0.sendMsgBuf(32636928L, 1, 8, stmp);
      delay(100);
  }
}
void transmitPGN127489(int engineInstance, float engineOilPress, float engineOilTemp, float engineCoolantTemp, float battery,
  float fuelRate, float engineHours, float engineCoolantPress, float engineFuelPress, float engineLoad, float engineTorque, bool flagCheckEngine,
  bool flagOverTemp, bool flagLowOilPress, bool flagLowOilLevel, bool flagLowFuelPress, bool flagLowSystemVoltage, bool flagLowCoolantLevel,
  bool flagWaterFlow, bool flagWaterInFuel, bool flagChargeIndicator, bool flagPreheatIndicator, bool flagHighBoostPress, bool flagRevLimitExceeded,
  bool flagEgrSystem, bool flagTPS, bool flagEmergencyStopMode, bool flagWarning1, bool flagWarning2, bool flagPowerReduction,
  bool flagMaintenanceNeeded, bool flagEngineCommError, bool flagSubThrottle, bool flagNeutralStartProtect, bool flagEngineShuttingDown){
  //if an engine parameter is not available, set it to 255
  unsigned int extpgn[26]; // {0, 208, 14, 170, 13, 151, 136, 236, 4, 37, 2, 112, 207, 11, 0, 255, 255, 255, 255, 1, 0, 0, 0, 0, 255, 255};  //decimal values
  unsigned char temp[8]; // {0,0,0,0,0,0,0,0};
  float v;
  extpgn[0]=engineInstance;

  v=engineOilPress;
  v=v*68.94757;
  //extpgn[2]=v/256;
  //extpgn[1]=v-(extpgn[2]*256);
  extpgn[2]=highByte((int) v);
  extpgn[1]=lowByte((int) v);  //this works well. I should change the code below to use this format.

  v=engineOilTemp;
  v=(((v-32)*5/9)+273)*100;
  extpgn[4]=v/256;
  extpgn[3]=v-(extpgn[4]*256);

  v=engineCoolantTemp;
  v=(((v-32)*5/9)+273)*100;
  extpgn[6]=v/256;
  extpgn[5]=v-(extpgn[6]*256);

  v=battery;
  v=v*100;
  extpgn[8]=v/256;
  extpgn[7]=v-(extpgn[8]*256);

  v=fuelRate;
  v=v*37.8541;
  extpgn[10]=v/256;
  extpgn[9]=v-(extpgn[10]*256);

  v=engineHours;
  v=v*3600;
  //extpgn[14]=v/16777216;
  //extpgn[13]=(v-(extpgn[14]*16777216))/65536;
  //extpgn[12]=(v-((extpgn[14]*16777216)+(extpgn[13]*65536)))/256;
  //extpgn[11]=v-((extpgn[14]*16777216)+(extpgn[13]*65536)+(extpgn[12]*256));
  int tempVar = (long) v >> 16;
  extpgn[14]=highByte(tempVar);
  extpgn[13]=lowByte(tempVar);
  tempVar = (long) v & 0xFFFF;
  extpgn[12]=highByte(tempVar);
  extpgn[11]=lowByte(tempVar);

  v=engineCoolantPress;
  v=v*68.94757;
  extpgn[16]=v/256;
  extpgn[15]=v-(extpgn[16]*256);

  v=engineFuelPress;
  v=v*689.4757;
  extpgn[18]=v/256;
  extpgn[17]=v-(extpgn[18]*256);

  extpgn[19] = 255; //nmea2000 reserved byte

  int engineStatus1P1 = B00000000;
  int engineStatus1P2 = B00000000;
  int engineStatus2 = B00000000;
  if (flagCheckEngine) engineStatus1P1 |= B00000001;
  if (flagOverTemp) engineStatus1P1 |= B00000010;
  if (flagLowOilPress) engineStatus1P1 |= B00000100;
  if (flagLowOilLevel) engineStatus1P1 |= B00001000;
  if (flagLowFuelPress) engineStatus1P1 |= B00010000;
  if (flagLowSystemVoltage) engineStatus1P1 |= B00100000;
  if (flagLowCoolantLevel) engineStatus1P1 |= B01000000;
  if (flagWaterFlow) engineStatus1P1 |= B10000000;

  if (flagWaterInFuel) engineStatus1P2 |= B00000001;
  if (flagChargeIndicator) engineStatus1P2 |= B00000010;
  if (flagPreheatIndicator) engineStatus1P2 |= B00000100;
  if (flagHighBoostPress) engineStatus1P2 |= B00001000;
  if (flagRevLimitExceeded) engineStatus1P2 |= B00010000;
  if (flagEgrSystem) engineStatus1P2 |= B00100000;
  if (flagTPS) engineStatus1P2 |= B01000000;
  if (flagEmergencyStopMode) engineStatus1P2 |= B10000000;

  if (flagWarning1) engineStatus2 |= B00000001;
  if (flagWarning2) engineStatus2 |= B00000010;
  if (flagPowerReduction) engineStatus2 |= B00000100;
  if (flagMaintenanceNeeded) engineStatus2 |= B00001000;
  if (flagEngineCommError) engineStatus2 |= B00010000;
  if (flagSubThrottle) engineStatus2 |= B00100000;
  if (flagNeutralStartProtect) engineStatus2 |= B01000000;
  if (flagEngineShuttingDown) engineStatus2 |= B10000000;

  extpgn[20]=engineStatus1P1;
  extpgn[21]=engineStatus1P2;
  extpgn[22]=engineStatus2;
  extpgn[23]=0;

  extpgn[24]=engineLoad;

  extpgn[25]=engineTorque;

  int cur=0;
  for(int i = 0; i<=3; i++){
      temp[0] = i; //frame counter
      if (i==0){
          temp[1] = 26; //total bytes in fast packet
          //send the first 6 bytes
          for(int j = 2; j<8; j++){
               temp[j]=extpgn[cur];
               cur++;
           }
      } else{
           for(int j = 1; j<8; j++){
               temp[j]=255;
           }
           //send the next 7 data bytes
           for(int j = 1; j<8; j++){
               temp[j]=extpgn[cur];
               cur++;
           }
      }
      CAN0.sendMsgBuf(32637184L, 1, 8, temp);
      delay(1);
  }
  //for debugging
  /*
  Serial.println();
  Serial.print("Data = ");
  for(int j = 0; j<26; j++){
    if (j<25){
      Serial.print(extpgn[j]);
      Serial.print(", ");
    } else {
      Serial.println(extpgn[j]);
    }
  }
  Serial.print("HexData = ");
  for(int j = 0; j<26; j++){
    if (j<25){
      Serial.print(extpgn[j],HEX);
      Serial.print(", ");
    } else {
      Serial.println(extpgn[j],HEX);
    }
  }
  */
}

jpjcb66

#34
Oct 09, 2014, 04:55 pm Last Edit: Oct 09, 2014, 04:58 pm by jpjcb66 Reason: 1
Thank you for your reply.
Here is my current code for this part :

Code: [Select]
// ++++++++++++++++++++++++++++++++++++ Engine Parameters, Dynamic ++++++++++++++++++++++++++++++++++++
  updateRate = 500; // 2 * / s
  priorite = 5;
  PGN = 127489;  // Paramètres environnementaux bus NMEA 2000 (N2K)
  source = 35;   // Airmar = 35
  adresse = priorite * 67108864 + PGN * 256 + source;
  float tempwc =  95; //TWEng;  // Celsius  Engine Water Temp
  long tempwk =  100 * ( tempwc + 273.15 );
  long tempw1 = ( tempwk & 0b1111111100000000 ) >> 8;  // mise en forme format CAN 16bits
  long tempw2 =   tempwk & 0b0000000011111111;

  float PressEng = 200;  // Lecture capteur pression resolution = 8 bits pour essai.
  long PressEng_ = 20 * PressEng;
  long PressEng1 = ( PressEng_ & 0b1111111100000000 ) >> 8;  // mise en forme format CAN 16bits
  long PressEng2 =   PressEng_ & 0b0000000011111111;

  message.id = adresse;
  message.ide = 1;
  message.rtr = 0;
  message.dlc = 8;
  message.data[0] = 0;   //  SID
  message.data[1] = 0;   //  Engine instance  8bits    0=Single Engine
  message.data[2] = 0;   //  doit etre  à 0 pour lecture 2 octets plus bas. Oil press = 0 si 255
  message.data[3] = PressEng2; //PressEng2;
  message.data[4] = PressEng1; //PressEng1;   //  Oil   Press huile 1=0,3  2=0,5  3=0,8  4=1b  28=7,2b
  message.data[5] = 255;   //  ????
  message.data[6] = tempw2;   //  Temperature eau moteur - 16 bits (sonde DS18B20)
  message.data[7] = tempw1;   //  Temperature eau
/* Serial.print("TEMPERATURE EAU MOTEUR : ");
Serial.print(tempw2);  Serial.print(" - ");
Serial.println(tempw1);
*/
  SendPaquet();

  message.data[1] = 1;  // 1 paquet supplémentaire
  message.data[2] = 0;  // Alternateur
  message.data[3] = 0;  // Alt
  message.data[4] = 0;  // Fuel rate
  message.data[5] = 0;  // Fuel rate
  message.data[6] = 1;  // Hour
  message.data[7] = 0;  // Hour
  message.data[8] = 0;  // Hour

  SendPaquet();

  message.data[1] = 2;  // 1 paquet supplémentaire
  message.data[2] = 4;  // Hour
  message.data[3] = 0;  // Coolant press
  message.data[4] = 0;  // Coolant press
  message.data[5] = 0;  // Fuel press
  message.data[6] = 0;  // Fuel press
  message.data[7] = 0;  // reserved
  message.data[8] = 0;  // Discrete Status 1

  SendPaquet();

  message.data[1] = 3;  // 1 paquet supplémentaire
  message.data[2] = 0;  // Discrete Status 1
  message.data[3] = 0;  // Discrete Status 2
  message.data[4] = 0;  // Discrete Status 2
  message.data[5] = 0;  // Percent Engine Load
  message.data[6] = 0;  // Percent Engine Torque

  SendPaquet();

  delay(updateRate);

spicetraders



I am using non-certified NMEA2000 cabling products that I had manufactured for my current project. I have several available for sale below if interested. See images.
2 meter cable (Male to Female) - $7.5 each
T adapter - $7 each
Male rear panel mount connector - $5 each


I have found that NEMA2000 is hardware wise follows the older DEVICENET so many parts interchange with out issues.

jpjcb66

#36
Oct 09, 2014, 05:14 pm Last Edit: Oct 09, 2014, 06:59 pm by jpjcb66 Reason: 1
Compliments, Beautiful Code.
But I have to try to translate Arduino uno.

I did not see how you code:
address = priority * 67108864 * 256 + PGN + source;

allen652

I should probably comment my code better (and more often).

jpjcb66: The first 3 bits of the id is the priority, the next 18 bits are the PGN, and the last 8 bits are the source address.
See the comments in my code above in void loop().

priority = 000
PGN = 011111001000000000
source = 00000000

00001111100100000000000000000 binary = 32636928 decimal

Code: [Select]
// send data:  id , extended frame, data length = 8, data buffer
  CAN0.sendMsgBuf(32636928L, 1, 8, stmp);

jpjcb66

#38
Oct 09, 2014, 06:45 pm Last Edit: Oct 10, 2014, 02:23 pm by jpjcb66 Reason: 1
@allen652

I understand !
You put "source" = 0x0
Code Airmar = 0x25 (35dec).
There exists an array of manufacturer codes ?
For example what is the Volvo Penta code ?


Your code is perfect, thank you infinitely.
jp
