Topic: DG408 wiring (Read 669 times) previous topic - next topic

srusha

Hello, I have DG408 (http://datasheets.maximintegrated.com/en/ds/DG408-DG409.pdf)

and it says in the following scheme that there is V+, V- and gnd, what does V- stands for?



thanks in advance,

silasmoeckel


Hello, I have DG408 (http://datasheets.maximintegrated.com/en/ds/DG408-DG409.pdf)

and it says in the following scheme that there is V+, V- and gnd, what does V- stands for?



thanks in advance,


Just what it says negative supply voltage.  That chip normally runs with 15v +- but supports a lot of different configurations. If you want to use it with positive voltage only connect v- to gnd as the datasheet says on page 6.

CrossRoads

If you were running from dual supply, like +12V/-12V, V- would be -12V.
If running from single +5 supply, V- goes to Gnd, per page 4.
Designing & building electrical circuits for over 25 years. Check out the ATMega1284P based Bobuino and other '328P & '1284P creations & offerings at  www.crossroadsfencing.com/BobuinoRev17.
Arduino for Teens available at Amazon.com.

srusha

Thats what I thought,

thanks for the quick reply.
