Author Topic: Capacitive Sensors too slow  (Read 144 times)
0 Members and 1 Guest are viewing this topic.
Offline Offline
Newbie
*
Karma: 0
Posts: 2
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Hey, I am using Capacitive Sensors as buttons  with the CapacitiveSensors.h library, 3 sensors in total. Arduino Nano is my platform

I coded a state machine with a timer interrupt.  I count in my Timer declaration to 16000 for 1 ms. In my ISR I count to a specific time, depends of what I want to do. For example count=1000 is 1 second.
If i press the first or the second button, i change the counter in ISR to 100 for scaning my buttons every 100ms and then i write digital to a BCD and then to a 7 Segment. Then if the first button was pressed, the counter changes to 1000.   My ISR does thw whole logic. The counter change i make in the void loop.
My problem: It doesn't work well. Sometimes if I tap the buttons, the numbers on the display counts in the right duration. If I keep my finger on the button, the number freezes on the display and it counts internal and after some time a number shows up.  If I change the counter to 400ms, then it works better for a reason, but the tapping doesn't work well.

I hope my english was not awefull an i explained it understandable.

I decreased my code to loop and ISR. You can also download the wohle code(sir4.ino):

#include <CapacitiveSensor.h>
Code:
#include <EEPROM.h>
#include <digitalWriteFast.h>



CapacitiveSensor   cs_2_A0 = CapacitiveSensor(2,A0);        // 10M resistor between pins 2 & A0, pin A0 is sensor pin, add a wire and or foil if desired
CapacitiveSensor   cs_2_A1 = CapacitiveSensor(2,A1);        // 10M resistor between pins 2 & A1, pin A1 is sensor pin, add a wire and or foil
CapacitiveSensor   cs_2_A2 = CapacitiveSensor(2,A2);        // 10M resistor between pins 2 & A2, pin A2 is sensor pin, add a wire and or foil


#define BCD_D1 10
#define BCD_C1 11
#define BCD_B1 12
#define BCD_A1 9

#define BCD_D2 7
#define BCD_C2 6
#define BCD_B2 5
#define BCD_A2 8

#define S1 4
#define S2 3

#define DP1 A4
#define DP2 A5



int iAddr = 0;
int iCountleft=0;
int iCountright=0;
int iTimenumber = 0;
int iLeftnumber;
int iRightnumber;
int iCounter=0;
//int iCounter1=0;
//int iCounter2=1000;
int iCount_button=0;
int iCount_buttonstart=0;
int iCount_isr=100;
int iSoundcount = 0;
//int total1, total2, total3;
//int iStorenumber;
//int def_seconds=0;
//int def_min=59;
int iMinutes;
int iSeconds;
int iRandnumber;
//int iDP = HIGH;

boolean bStart=  false;
boolean bStop;
boolean bReset = false;
boolean bPlaysound=false;
boolean bPresound=false;
boolean bButton=false;
boolean bPressed = false;



long total1;
long total2;
long total3;


void setup()
{


   cs_2_A0.set_CS_AutocaL_Millis(0xFFFFFFFF);     // turn off autocalibrate on channel 1 - just as an example
   cs_2_A1.set_CS_AutocaL_Millis(0xFFFFFFFF);
   cs_2_A2.set_CS_AutocaL_Millis(0xFFFFFFFF);

   iTimenumber=EEPROM.read(iAddr);



//********TIMER Declaration***********//
   cli();
   TCCR1A= 0;
   TCCR1B= 0;
   OCR1A=16000;

   TCCR1B |= (1 << WGM12);
   TCCR1B |= (1 << CS10);   //Prescaler =1

   TIMSK1 |= (1 << OCIE1A);
   // enable global interrupts:
   sei();

 Serial.begin(9600);

}

void loop()

{

   if(bBullshit==false)
      {
        iCount_isr=1000;
      }
   if(bBullshit==true)
      {
        iCount_isr=200;
      }

   to_BCD_left();
   to_BCD_right();

   if(bPresound==true)
        {
          presound();
        }

    if(bPlaysound ==true) //Sound Funktion
       {
        sound();
        bPlaysound = false;
       }


}


ISR(TIMER1_COMPA_vect)
{

  if(iCounter>=iCount_isr)
    {
        iRandnumber = random(1,3);
        iCounter=0;

        total1 =  cs_2_A1.capacitiveSensor(30);
        total2 =  cs_2_A0.capacitiveSensor(30);
        total3 =  cs_2_A2.capacitiveSensor(30);



          if(bStart==true)
            {
              iTimenumber--;

              iLeftnumber = iTimenumber / 10;
              iRightnumber = iTimenumber % 10;
              digitalWriteFast(DP1, LOW);
              iCountright= iRightnumber;
              iCountleft = iLeftnumber;


              if(total1>6000)

                {
                  bStart=false;

                }

              if(iTimenumber==20)
                 {
                   bPresound=true;
                 }
              if(iTimenumber==0)
                 {
                  bStart=false;
                  bPlaysound=true;
                 }

            }

            else
             {

               digitalWriteFast(DP1, HIGH);
               digitalWriteFast(DP2, HIGH);
               if(total1>6000)
                   {
                     bButton=true;
                     iCount_buttonstart++;

                       if(iCount_buttonstart>3)
                           {
                            if(iTimenumber!=0)
                                 {
                                   EEPROM.write(iAddr, 0);}
                                   iTimenumber=0;

                                 }
                   }

                if(total1<2000)
                   {
                     if(iCount_buttonstart<=3 && iCount_buttonstart>0)
                         {
                           bStart= true;
                           EEPROM.write(iAddr, iTimenumber);
                           iCount_buttonstart=0;
                           iCount_isr=1000;
                          }
                   }


               else if(total2 < 2000 && total3 < 2000)
                  {

                    bPressed = false;
                  }


               if (total2 >6000)
                   {
                     bPressed=true;
                     if(iTimenumber>=60)
                      {
                          iTimenumber=-1;
                      }

                      iTimenumber++;
                  }

               if(total3 >6000)
                  {
                        bPressed=true;
                        if(iTimenumber<0)
                        {
                            iTimenumber=61;
                        }

                    iTimenumber--;
                  }

                    iLeftnumber = iTimenumber / 10;
                    iRightnumber = iTimenumber % 10;
                    iCountright= iRightnumber;
                    iCountleft = iLeftnumber;


             }

     }

     iCounter++;
}


}



* sir4.ino (13.14 KB - downloaded 5 times.)
Logged

Global Moderator
Boston area, metrowest
Offline Offline
Brattain Member
*****
Karma: 443
Posts: 23834
Author of "Arduino for Teens". Available for Design & Build services. Now with Unlimited Eagle board sizes!
View Profile
WWW
 Bigger Bigger  Smaller Smaller  Reset Reset

Does that compile okay?
I see bBullshit, but its datatype is not declared and it never changes value.
I also see bPresound and presound, but presound is not declared.
Logged

Designing & building electrical circuits for over 25 years. Check out the ATMega1284P based Bobuino and other '328P & '1284P creations & offerings at  www.crossroadsfencing.com/BobuinoRev17.
Arduino for Teens available at Amazon.com.

Offline Offline
Newbie
*
Karma: 0
Posts: 4
Computer scientist located in Berlin, Germany Interested in signal processing, sensors and user interfaces
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Capacitive buttons are generally slow in responding, so if you build some kind of stopwatch you will be better off with conventional hardware buttons.
