Hi, I have a very basic question, but I want to be sure that I won't blow anything up...
For a battery holder like in the image below (that can hold 8 AA batteries), can I just put some wires on the places where I drawed (yes in Paint  smiley-cool ) blue lines to make a 4 AA battery holder of it?

Thanks for your help!
Bram
Logged

Global Moderator
UK
Offline Offline
Brattain Member
*****
Karma: 302
Posts: 26285
I don't think you connected the grounds, Dave.
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

You could do that, or you could
A) add one wire
B) move one wire
Logged

"Pete, it's a fool looks for logic in the chambers of the human heart." Ulysses Everett McGill.
Do not send technical questions via personal messaging - they will be ignored.

Left Coast, CA (USA)
Offline Offline
Brattain Member
*****
Karma: 361
Posts: 17294
Measurement changes behavior
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

In theory yes, but in practice I think you might find it somewhat difficult soldering wire jumper(s) as the metal of the contacts and springs on some don't work well with normal solder. Also when completed you should really measure the resulting voltage with a multimeter to make sure the pack is generating the voltage you expect. Such meters are available very inexpensive and are a 'must have' for any work with an arduino project.

Logged

Offline Offline
Edison Member
*
Karma: 33
Posts: 1447
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Sure, you should also be able to just connect a single wire from the last battery to the last one you want connected. Check things with an ohmmeter if you want to be sure.
Logged

Lincoln, England
Offline Offline
Full Member
***
Karma: 8
Posts: 194
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

As well as finding the spring contacts are difficult to solder too, you may also find that the heat of the soldering iron melts the plastic.
Logged

Global Moderator
UK
Offline Offline
Brattain Member
*****
Karma: 302
Posts: 26285
I don't think you connected the grounds, Dave.
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

You may find you could thread the bared end of the wire through the coils of the spring, to be held in place by the presence of the last battery.
It depends on how reliable you need the arrangement to be.
Logged

"Pete, it's a fool looks for logic in the chambers of the human heart." Ulysses Everett McGill.
Do not send technical questions via personal messaging - they will be ignored.

Left Coast, CA (USA)
Offline Offline
Brattain Member
*****
Karma: 361
Posts: 17294
Measurement changes behavior
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Or just find or make brass or copper rods the same size as AA cells and there you go.  smiley-wink


Logged

Ayer, Massachusetts, USA
Offline Offline
Edison Member
*
Karma: 54
Posts: 1848
View Profile
WWW
 Bigger Bigger  Smaller Smaller  Reset Reset

If you have a Radio Shack nearby (that is still open), I would be tempted to wander down there, and see if they have a 4 AA holder.

I've seen people making fake batteries for using external power for camera flash units, by getting an appropriate sized wooden dowel, and drilling it, and installing a metal pin of the appropriate size (and the last battery, actually has the wires to connect to the external battery).
Logged

Denmark
Offline Offline
Full Member
***
Karma: 10
Posts: 220
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Or just find or make brass or copper rods the same size as AA cells and there you go.  smiley-wink

I have an even simpler solution.

I simply stick some fired .308 Win cases in the holder instead of batteries.
Approx the same diameter, and less than one millimeter longer.


* image.jpg (117.48 KB, 800x597 - viewed 28 times.)
« Last Edit: March 18, 2014, 03:58:24 pm by Peter_I » Logged

Bob Pease: "My favorite programming language is ... solder."

Global Moderator
UK
Offline Offline
Brattain Member
*****
Karma: 302
Posts: 26285
I don't think you connected the grounds, Dave.
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Quote
Bob Pease: "My favorite programming language is ... solder."
Steve Ciarcia
Logged

"Pete, it's a fool looks for logic in the chambers of the human heart." Ulysses Everett McGill.
Do not send technical questions via personal messaging - they will be ignored.

Heemskerk, Netherlands
Offline Offline
Sr. Member
****
Karma: 10
Posts: 367
View Profile
WWW
 Bigger Bigger  Smaller Smaller  Reset Reset

Quote
Bob Pease: "My favorite programming language is ... solder."
Steve Ciarcia
God.... that is an old one...... I remember his articles in Byte in the old days  smiley-mr-green
Logged

Global Moderator
UK
Offline Offline
Brattain Member
*****
Karma: 302
Posts: 26285
I don't think you connected the grounds, Dave.
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

I suspect Bob Pease was even older.
I loved his articles, even if most of the time, I didn't understand the subtilties of analogue design.
Logged

"Pete, it's a fool looks for logic in the chambers of the human heart." Ulysses Everett McGill.
Do not send technical questions via personal messaging - they will be ignored.

Leeds, England
Offline Offline
God Member
*****
Karma: 15
Posts: 648
Quick, chuck it in the bin before the boss finds out...
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Back on topic, you can buy dummy batteries for this purpose. Look like (or at least similar to) a battery but it's just a metal strip from one end to the other!

I've just picked a listing at random:

http://www.ebay.co.uk/itm/12-pcs-Pack-Dummy-Battery-AA-Size-Conduct-Conductor-Electric-Current-Ultracell-/181182376696?pt=LH_DefaultDomain_0&hash=item2a2f4faaf8
Logged

Beginners guide to using the Seeedstudio SIM900 GPRS/GSM Shield

Denmark
Offline Offline
Full Member
***
Karma: 10
Posts: 220
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Quote
Bob Pease: "My favorite programming language is ... solder."
Steve Ciarcia

Bob Pease
I picked it up from here: http://www.ti.com/ww/en/bobpease/index.html
(But whether he made it up or picked it up, that's a good question)
Logged

Bob Pease: "My favorite programming language is ... solder."

Offline Offline
Newbie
*
Karma: 0
Posts: 25
View Profile
 Bigger Bigger  Smaller Smaller  Reset Reset

Thanks for the mass amount of answer and for the history of Steve and Bob  smiley-razz
I'll try to solder it, if I mess up, I'll just buy another one. They're so cheap smiley and I'll measure the Vout with a multimeter at school before I juice my 2 hacked servo's (360°) with it.

If you have a Radio Shack nearby (that is still open), I would be tempted to wander down there, and see if they have a 4 AA holder.
We don't have that shop in Belgium. Everyone is always talking about Radioshack on this forum smiley-sad
