Topic: Buidling Arduino Controller for Hamamatsu C12666MA mini-spectrometer (Read 869 times) previous topic - next topic

spectrovan

Currently, I'm in the process of attempting to build an arduino-based spectrometer with a Hamamatsu C12666MA as the light sensor that transmits all my data to the controller and plots it onto the serial plotter. To start, I've tried looking at a past project done on GitHub using the arduino spectrometer and trying out the code file provided to see how it worked. The code gave me rather strange outputs on the serial monitor and plotter. Here's the code below and I have attached a png of the serial plotter output.

The attached pic of the output on the serial plotter shows the graph when I shine a flashlight on the sensor and then turn it off. The graph's normal leveling area is at around 90 on the y-axis. Is this supposed to be the output? Is the software bugged? The demonstration video for this project uses the software Processing instead of Arduino to display the data. Any help with better understanding would be much appreciated. Thank you.

#define SPEC_GAIN        A0
//#define SPEC_EOS         NA
#define SPEC_ST          A1
#define SPEC_CLK         A2
#define SPEC_VIDEO       A3
#define WHITE_LED        A4
#define LASER_404        A5

#define SPEC_CHANNELS    256
uint16_t data[SPEC_CHANNELS];

void setup() {

  //pinMode(SPEC_EOS, INPUT);
  pinMode(SPEC_GAIN, OUTPUT);
  pinMode(SPEC_ST, OUTPUT);
  pinMode(SPEC_CLK, OUTPUT);

  pinMode(WHITE_LED, OUTPUT);
  pinMode(LASER_404, OUTPUT);
  digitalWrite(WHITE_LED, LOW);
  digitalWrite(LASER_404, LOW);


  //digitalWrite(WHITE_LED, HIGH);
  //digitalWrite(LASER_404, HIGH);

  digitalWrite(SPEC_GAIN, HIGH);
  digitalWrite(SPEC_ST, HIGH);
  digitalWrite(SPEC_CLK, HIGH);
  digitalWrite(SPEC_GAIN, HIGH); //LOW Gain
  //digitalWrite(SPEC_GAIN, LOW); //High Gain

  //Serial.begin(9600);
  Serial.begin(115200);
}

void readSpectrometer()
{
  //int delay_time = 35;     // delay per half clock (in microseconds).  This ultimately conrols the integration time.
  int delay_time = 1;     // delay per half clock (in microseconds).  This ultimately conrols the integration time.
  int idx = 0;
  int read_time = 35;      // Amount of time that the analogRead() procedure takes (in microseconds) (different micros will have different times)
  int intTime = 100;
  int accumulateMode = false;
  int i;

  // Step 1: start leading clock pulses
  for (int i = 0; i < SPEC_CHANNELS; i++) {
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
  }

  // Step 2: Send start pulse to signal start of integration/light collection
  digitalWrite(SPEC_CLK, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, HIGH);
  digitalWrite(SPEC_ST, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, HIGH);
  digitalWrite(SPEC_ST, HIGH);
  delayMicroseconds(delay_time);

  // Step 3: Integration time -- sample for a period of time determined by the intTime parameter
  int blockTime = delay_time * 8;
  long int numIntegrationBlocks = ((long)intTime * (long)1000) / (long)blockTime;
  for (int i = 0; i < numIntegrationBlocks; i++) {
    // Four clocks per pixel
    // First block of 2 clocks -- measurement
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);

    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
  }


  // Step 4: Send start pulse to signal end of integration/light collection
  digitalWrite(SPEC_CLK, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, HIGH);
  digitalWrite(SPEC_ST, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, LOW);
  delayMicroseconds(delay_time);
  digitalWrite(SPEC_CLK, HIGH);
  digitalWrite(SPEC_ST, HIGH);
  delayMicroseconds(delay_time);

  // Step 5: Read Data 2 (this is the actual read, since the spectrometer has now sampled data)
  idx = 0;
  for (int i = 0; i < SPEC_CHANNELS; i++) {
    // Four clocks per pixel
    // First block of 2 clocks -- measurement
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, LOW);

    // Analog value is valid on low transition
    if (accumulateMode == false) {
      data[idx] = analogRead(SPEC_VIDEO);
    } else {
      data[idx] += analogRead(SPEC_VIDEO);
    }
    idx += 1;
    if (delay_time > read_time) delayMicroseconds(delay_time - read_time);   // Read takes about 135uSec

    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);

    // Second block of 2 clocks -- idle
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
  }

  // Step 6: trailing clock pulses
  for (int i = 0; i < SPEC_CHANNELS; i++) {
    digitalWrite(SPEC_CLK, LOW);
    delayMicroseconds(delay_time);
    digitalWrite(SPEC_CLK, HIGH);
    delayMicroseconds(delay_time);
  }
}

void print_data()
{
  for (int i = 0; i < SPEC_CHANNELS; i++)
  {
    Serial.print(data);
    Serial.print(',');
  }
  Serial.print("\n");
}

void loop()
{
//  digitalWrite(LASER_404, HIGH);
//  readSpectrometer();
//  digitalWrite(LASER_404, LOW);
//  print_data();
//  delay(10);

//  digitalWrite(WHITE_LED, HIGH);
//  readSpectrometer();
//  digitalWrite(WHITE_LED, LOW);
//  print_data();
//  delay(10);

  readSpectrometer();
  print_data();
  delay(10);
}
