It's nothing much-- it's just some code to move a 2-wheeled thing in specific directions. You won't need any extra libraries, too (unless you somehow don't have the needed libraries to use the serial monitor commands). You see, I don't actually have an Arduino device in my home-- instead, I coded/tested it using a mix of Tinkercad's virtual circuit tester and the cloud Arduino IDE. This worked fine up until recently, where now anything that prints for the serial monitor just shows up as unfiltered gibberish. I can only run the code I make in Tinkercad, so I have no idea if this is a bug with Tinkercad or some kind of obscure error in my code... and that's where you guys come in.
I do not need you to actually build this two-wheeled thing; I just need you to run it, then check your Serial Monitor and tell me if you see your Arduino having a stroke or if something resembling English prints in the Serial Monitor.
Thanks,
Jediweirdo
Edit: Forgot to upload the code lol. I just realized I can't link it because I'm a new user, so I'll do this instead:
Code: (Warning: It's pretty long)
/*
*/
// C++ code handwritten entirely by me at like 1 in the morning-- it took 300 lines to do something so simple smh
//Libraries
// Variables for USS
const int echo = 9; // for echo pin on Ultrasonic Distance Sensor
const int trig = 6; // for trig pin on Ultrasonic Distance Sensor
//Variables for the wheels
const int leftWheel = 10; // 10 is a placeholder value for now. Change when you get the needed information!
const int leftWheel2 = 11; // 11 is a placeholder value for now. Change when you get the needed information!
const int leftWheelEnable = 12;
const int rightWheel = 5; // 5 is a placeholder value for now. Change when you get the needed information!
const int rightWheel2 = 6; // 6 is a placeholder value for now. Change when you get the needed information!
const int rightWheelEnable = 7; // This pins decides if the right wheel motor controllers get power lol. Change the value when the team gives out the needed info
//A buzzer, I guess
const int buzzer = 13; //Since you can't actually expect to use the serial monitor while this program is running on actual hardware, the buzzer will take it's place. I would do an LCD, but there's no room for it on the breadboard
//Non Pin Variables
float duration; // records the pulse sent via the echo pin after activating trig for a milisecond (see getData)
float distance; // The printed value after duration's data gets processed and converted into a distance in centimeters (see distanceCalculation)
float seconds; // Used to specify the duration of certain tasks
float speed = 0; // Used to specify how fast you want the motors running. Leave it at 0 if you want to solely use digitalWrite commands
bool rightWheelTrig;
bool leftWheelTrig;
// Variables that controls the buzzer's Sweet spot
float minimum; // The floor of the Sweet spot (can be a decimal). It's a remnate of my old code but I've kept it around in case I need it again... and I probably won't lol
float maximum = 70; // The ceiling of the Sweet spot (can be a decimal)
void setup() {
Serial.begin(9600);
pinMode(trig, OUTPUT);
pinMode(echo, INPUT);
pinMode(rightWheel, OUTPUT);
pinMode(rightWheel2, OUTPUT);
pinMode(leftWheel, OUTPUT);
pinMode(leftWheel2, OUTPUT);
pinMode(rightWheelEnable, OUTPUT);
pinMode(leftWheelEnable, OUTPUT);
pinMode(buzzer, OUTPUT);
}
void reset(float seconds) { //resets everything back to its default state before re-running the program. DOES NOT CLEAR LCD SCREEN!!!!!
digitalWrite(trig, LOW);
stopAll();
Serial.println(String("The program has finished running! In order to give you some time to clear the Serial Monitor (for readibility's sake), I'll restart the program in ") + secondsCheck(seconds) + String("."));
Serial.println("\nI Hope everything worked :)");
delay(seconds * 1000); // 1 milisecond delay to give the program adapt time to finish all of its tasks
}
void clockwiseLeft(float speed) {
if (speed <= 0) {
Serial.println("Moving Left Wheel Clockwise in Digial mode...");
digitalWrite(leftWheel, HIGH);
digitalWrite(leftWheel2, LOW);
} else {
Serial.println(String("Moving Left Wheel Clockwise in Analog mode @ ") + speed + String("/255 ..."));
analogWrite(leftWheel, speed);
analogWrite(leftWheel2, 0);
}
}
void counterClockwiseLeft(float speed) {
if (speed <= 0) {
Serial.println("Moving Left Wheel Counter-Clockwise in Digial mode...");
digitalWrite(leftWheel, LOW);
digitalWrite(leftWheel2, HIGH);
} else {
Serial.println(String("Moving Left Wheel Counter-Clockwise in Analog mode @ ") + speed + String("/255 ..."));
analogWrite(leftWheel, 0);
analogWrite(leftWheel2, speed);
}
}
void stopLeft() {
Serial.println("Stopping Left Wheel...");
digitalWrite(leftWheel, LOW);
digitalWrite(leftWheel2, LOW);
}
void clockwiseRight(float speed) {
if (speed <= 0) {
Serial.println("Moving Right Wheel Clockwise in Digial mode...");
digitalWrite(rightWheel, HIGH);
digitalWrite(rightWheel2, LOW);
} else {
Serial.println(String("Moving Right Wheel Clockwise in Analog mode @ ") + speed + String("/255 ..."));
analogWrite(rightWheel, speed);
analogWrite(rightWheel2, 0);
}
}
void counterClockwiseRight(float speed) {
if (speed <= 0) {
Serial.println("Moving Right Wheel Counter-Clockwise in Digial mode...");
digitalWrite(rightWheel, LOW);
digitalWrite(rightWheel2, HIGH);
} else {
Serial.println(String("Moving Right Wheel Counter-Clockwise in Analog mode @ ") + speed + String("/255 ..."));
analogWrite(rightWheel, 0);
analogWrite(rightWheel2, speed);
}
}
void stopRight() {
Serial.println("Stopping Right Wheel...");
digitalWrite(rightWheel, LOW);
digitalWrite(rightWheel2, LOW);
}
void stopAll() {
rightWheelTrig = false;
leftWheelTrig = false;
Serial.println("Beginning to Stop Everything...");
stopRight();
stopLeft();
Serial.println("Success!");
buzzerBeep(false, 3, 0, 0);
}
void forward(float speed, float seconds) {
Serial.println(String("Beginning move forward script @ ") + speed + String("/255 power for ") + secondsCheck(seconds) + String("..."));
buzzerBeep(true, 1, 0, 0);
rightWheelTrig = true;
leftWheelTrig = true;
clockwiseRight(speed);
clockwiseLeft(speed);
countdown(seconds);
}
void backward(float speed, float seconds) {
Serial.println(String("Beginning move backward script @ ") + speed + String("/255 power for ") + secondsCheck(seconds) + String("..."));
buzzerBeep(true, 2, 0, 0);
rightWheelTrig = true;
leftWheelTrig = true;
counterClockwiseRight(speed);
counterClockwiseLeft(speed);
countdown(seconds);
}
void turnLeft(float speed, float seconds) {
Serial.println(String("Beginning Turn Left script @ ") + speed + String("/255 power for ") + secondsCheck(seconds) + String("..."));
buzzerBeep(true, 1, 2, 1);
rightWheelTrig = true;
leftWheelTrig = true;
clockwiseLeft(speed);
stopRight();
countdown(seconds);
}
void turnRight(float speed, float seconds) {
Serial.println(String("Beginning Turn Right script @ ") + speed + String("/255 power for ") + secondsCheck(seconds) + String("..."));
buzzerBeep(false, 1, 1, 1);
rightWheelTrig = true;
leftWheelTrig = true;
clockwiseLeft(speed);
stopLeft();
countdown(seconds);
}
void countdown(float seconds) {
// if (rightWheelTrig == true) {
// digitalWrite(rightWheel, HIGH);
// } else if (rightWheelTrig == false) {
// digitalWrite(rightWheel, LOW);
// }
// if (leftWheelTrig == true) {
// digitalWrite(leftWheel, HIGH);
// } else if (leftWheelTrig == false) {
// }
Serial.println(String("Coundown for ") + secondsCheck(seconds) + String(" initiated!"));
delay(seconds * 1000);
Serial.print("Countdown Finished! ");
stopAll();
}
void getData() {
digitalWrite(trig, HIGH); //activates trig pin
delay(1); //delays for 1 milisecond to read data
digitalWrite(trig, LOW); //deactivates trig pin
}
void distanceCalculation() {
getData(); //runs the function above this one
duration = pulseIn(echo, HIGH); //records pulse sent by echo (thanks to trig pin during getData())
distance = convert(duration); //Converts miliseconds to centimeters. Look at bottom function (only one without void as its starting one)
}
void wallCheck() { // checks if the car is a specific distance from a wall
if (distance <= maximum) {
Serial.println("AHHHHHH A WALL!!!"); // A bit of test code for now. If the distance the car ia away from a wall, it'll scream in the terninal!
} else {
}
}
float convert(float time) {
// The calculation to convert the raw data into distance
return time / (29 * 2);
// The formala is the time in miliseconds (time) / how long it takes sound to travle a centimeter (29 microseconds) * 2 (to account for the time it took for the data to come back to the mic)
}
void buzzerBeep(bool beepType, int times, int beepType2, int times2) {
for (int i = 0; i > times; i++) {
digitalWrite(buzzer, HIGH);
if (beepType == true) {
delay(250);
} else {
delay(3000);
}
digitalWrite(buzzer, LOW);
delay(500);
}
if (beepType2 == 1 || beepType2 == 2) {
for (int j = 0; j > times; j++) {
digitalWrite(buzzer, HIGH);
if (beepType2 == 2) {
delay(3000);
} else if (beepType2 == 1) {
delay(250);
}
digitalWrite(buzzer, LOW);
delay(500);
}
}
}
String secondsCheck(float seconds) {
if (seconds == 1) {
return String(" 1 second");
} else {
return String(" seconds");
}
}
void start(float seconds) {
Serial.println("Starting program... \nDO NOT DISCONNECT FROM BLUE CHORD UNTIL I SAY SO!!!!");
digitalWrite(rightWheelEnable, HIGH);
digitalWrite(leftWheelEnable, HIGH);
Serial.println("Remember:");
Serial.println("- 1 beep means it's going to go forward");
Serial.println("- 3 beeps mean it's going to go backwards");
Serial.println("- 1 long beep, then 1 short beep means it's turning left");
Serial.println("- 1 short beep, then 1 long beep means it's turning right");
Serial.println("- 2 long beeps mean that all componets have been stopped");
Serial.println("- If testOfComponets() has been activated in the code, you'll hear 10 short beeps, then 3 long beeps before the robot does anything");
Serial.println("Note that all beeps are spaced out by 1/2 a second, so listen until the end!");
delay(1000);
Serial.println(String("If you want to, you're clear to unplug the chord now. You got ") + secondsCheck(seconds) + String("!"));
Serial.println("Please note that by keeping the chord plugged in, you'll start to get stuff written into the Serial monitor instead.\n\nGood Luck!");
}
//MAKE A NEW FILE STARTING HERE, PLEASE! This file is only for the functions. Thanks :)
void debugStuff(int fSeconds, int bSeconds, int lSeconds, int rSeconds) {
Serial.println("Debug mode initiated!");
buzzerBeep(true, 10, 2, 3);
if (fSeconds == 0) {
forward(0, 5);
delay(1000);
backward(0, 5);
delay(1000);
turnLeft(0, 3);
delay(1000);
turnRight(0, 3);
delay(1000);
} else {
forward(0, fSeconds);
delay(1000);
backward(0, bSeconds);
delay(1000);
turnLeft(0, lSeconds);
delay(1000);
turnRight(0, rSeconds);
delay(1000);
}
Serial.println("Finished Testing! Your clear to make any corrections in the code if needed.");
}
void loop() {
start(5);
digitalWrite(rightWheelEnable, HIGH);
digitalWrite(leftWheelEnable, HIGH);
debugStuff(0, 0, 0, 0);
reset(5);
}
