I have been using a Adafruit MAX31865 board connected to an Arduino Nano RP2040 Connect via SPI.
The sketch/board/sensor generally works correctly, reporting accurate temperatures.
When making a change and uploading a new sketch to the arduino the MAX31865 stops working and enters a fault state.
Hardware:
Arduino Nano RP2040 Connect (I cannot see any Revision indicated on the board)
Adafruit MAX31865 RTD to SPI board.
PT100 RTD 3 wire
I can reproduce this with multiple sensors and arduinos.
Code:
I am interacting with the SPI sensor with the Adafruit library:
Library installed: 1.6.0
Board installed: Arduino Mbed OS Nano Board 4.0.2
Arduino App: 1.8.19 (Mac OS 11.7.4)
I can reproduce this error using the default example sketch:
I have made no changes to the example sketch, I wired the pins to use the default Arduino ones for the board so no changes are needed.
Before uploading a new sketch to the arduino, serial monitor:
RTD value: 8349
Ratio = 0.25479126
Resistance = 109.56024170
Temperature = 24.55
This is the desired output and works correctly.
After a new sketch is uploaded successfully:
RTD value: 0
Ratio = 0.00000000
Resistance = 0.00000000
Temperature = -242.02
Fault 0x40
RTD Low Threshold
Once I physically disconnect everything and plug the SPI device back in or reboot the Arduino it works correctly again. I connected everything with JST connectors which is why I can unplug everything.
I would like advice on two things:
- How to resolve this issue, I would like to be able to make changes to code without having to physically reset everything.
- How to detect when the SPI device is not plugged in / responding. With this library it just returns a zero value which is ambiguous.
I tried pulling the CS pin low or high in the setup() stage of the sketch to see if I could reset things but I hit the limits of my knowledge.
The board is connected to the Arduino's ground and 3V3 output. I have measured and it draws less than the max current.
Edit: I actually have no idea whats going on here. If I unplug the arduino from power the error remains. If I unplug the board from the arduino while unplugged from power the error remains. Only if I connect the board while the arduino is already powered on does everything work OK.
