Hello,
I am currently doing a project to measure the temperature with 3 different thermocouples using the max6675 breakboards.
my circuit setup is the following
1 arduino uno rev 3
3 max 6675 breakboards
3 thermocouples
for each breakboard I connected them respectively to:
SO: 11 , 12, 13
CS: 10, 9, 8
SCK: 7, 6, 5
so for example first MAX is connected to the pins 11, 10 and 7 respectively.
the 5V and gnd of the arduino are connected each of them to a plate that all the 5V and gnd of the max are connected to.
my measurement code looked like this:
///////////////////
//libraries////////
///////////////////
// -SD reader
#include <SPI.h>
#include <SD.h>
// -Temp measurement
#include "max6675.h"
//****************/
//end libraries////
//****************/
//SD info
#define SD_CS 4 // Chip select line for SD card on Shield
//file definition values
String fileName="run"; // file name for storing data
int fileNumber=0; // file index for fileName
File myFile; // file object
//temp read
#define numberOfMeasurements 3
#define maxNumberOfPointsStored 15
int pinSO[numberOfMeasurements] = {13,12,11};
int pinCS[numberOfMeasurements] = {10, 9, 8};
int pinSCK[numberOfMeasurements]= { 7, 6, 5};
MAX6675 thermocouples[numberOfMeasurements] = {
MAX6675(pinSCK[0], pinCS[0], pinSO[0]),
MAX6675(pinSCK[1], pinCS[1], pinSO[1]),
MAX6675(pinSCK[2], pinCS[2], pinSO[2])
};
const uint32_t minTimeMax6675=500; // min time in miliseconds for correct (temperature) measurement with the max6675
// in case that there are different sensors
uint32_t minTimes[numberOfMeasurements]={minTimeMax6675,minTimeMax6675,minTimeMax6675}; // min times list for each measurement
uint32_t minTime; // min time in miliseconds for correct (temperature) measurement with the max6675
// time variables
uint32_t previousTime=0; // variable to save previous time to ensure that the measurement takes enought time
uint32_t initialTime=0; // variable to save original time when the measurement began
//measurement calculation
int numberOfTimeSteps=10;
float timeSteps[]={1000, // 1 sec time steps for the different time stamps as the time increase the measurements will be less frequently
5000, // 5 sec
10000, // 10 sec
30000, // 30 sec
60000, // 1 min
120000, // 2 min
150000, // 2.5 min
180000, // 3 min
300000, // 5 min
600000 // 10 min
};
float timeStamps[]={3600000, // 1 hr
7200000, // 2 hr
10800000, // 3 hr
21600000, // 6 hr
36000000, // 10 hr
64800000, // 18 hr
118800000, // 33 hr
212400000, // 59 hr
378000000, // 105 hr
676800000 // 188 hr
};
int currentInt=0;
// float updateIntervalFirstPart=1000 ; // time interval to return a measurement value in miliseconds
// float updateIntervalSecondPart=10000 ; // time interval to return a measurement value in miliseconds
// float updateInterval;
uint32_t lastUpdateTime = 0; // time counter since last returned measurement value
float sumTime=0; // sum of time values in time interval of updateInterval
float sumMeasures[numberOfMeasurements]; // sum of measurements values in time interval of updateInterval
int counterPoints=0; // counter of numbers of points measured in a time interval of updateInterval
float storedMeasures[numberOfMeasurements][maxNumberOfPointsStored]; // saving values for each measurement
float storedTime[maxNumberOfPointsStored]; // saving time values of each measurement done (ie., storedMeasures)
bool writeFileOnOff=1; //if 1 it will write write data if 0 it will not write it anywhere
bool typeOfWrintingSDOrBuffer=0; //if 1 it will write in SD if 0 it will write in buffer
int measureIndex=0; // counter of numbers of stored measurements points
char dataStr[100] = "";
char buffer[7];
void setup() {
Serial.begin(9600);
while (!Serial);
if (writeFileOnOff & typeOfWrintingSDOrBuffer) {
Serial.print("Initializing SD card...");
if (!SD.begin(SD_CS)) {
Serial.println("failed!");
} else {
Serial.println("OK!");
}
} else {
if (typeOfWrintingSDOrBuffer==0) {
Serial.print("printing on buffer...");
Serial.println("");
}
}
initialTime=millis();
for (int i = 0; i < numberOfMeasurements; i++) { // Start loop from the second element
if (minTimes[i] >= minTime) {
minTime = minTimes[i]; // Update minValue if current element is smaller
}
}
// updateInterval=updateIntervalFirstPart;
}
void writeFile () {
if (writeFileOnOff) {
if (typeOfWrintingSDOrBuffer) {
Serial.print("writing in SD...");
myFile=SD.open(fileName+".csv",FILE_WRITE);
if (myFile) {
myFile.print(storedTime[measureIndex]);
myFile.print(";");
for (int i = 0; i < numberOfMeasurements; i++) {
myFile.print(storedMeasures[i][measureIndex]);
myFile.println(";");
}
myFile.close();
} else {
Serial.print(fileName+".csv");
Serial.println("error while opening SD file");
}
} else {
// Serial.print("writing in buffer...");
//convert floats to string and assemble c-type char string for writing:
ltoa( storedTime[measureIndex],buffer,10); //convert long to charStr
strcat(dataStr, buffer); //add it to the end
strcat( dataStr, ", "); //append the delimiter
for (int i = 0; i < numberOfMeasurements; i++) {
dtostrf(storedMeasures[i][measureIndex], 5, 1, buffer); //5 is minimum width, 1 is precision; float value is copied onto buff
strcat( dataStr, buffer); //append the converted float
if (i!=numberOfMeasurements-1) {
strcat( dataStr, ", "); //append the delimiter
}
}
strcat( dataStr, 0); //terminate correctly
Serial.println(dataStr);
}
} else {
Serial.print("writing data flag OFF (change variable writeFileOnOff to 1)");
}
}
void loop () {
dataStr[0] = 0; //clean out string
unsigned long currentMillis = millis();
if (currentMillis - lastUpdateTime >= timeSteps[currentInt]) {
// update last display moment, once per second = once per 1000 millis
lastUpdateTime += timeSteps[currentInt];
if (lastUpdateTime>timeStamps[currentInt] & currentInt<numberOfTimeSteps) {
currentInt+=1;
Serial.println("increassing the timeStep of measurement");
while (1) {}
// updateInterval=updateIntervalSecondPart;
}
// storing a new average value
for (int i = 0; i < numberOfMeasurements; i++) {
storedMeasures[i][measureIndex] = sumMeasures[i] / counterPoints;
}
storedTime[measureIndex]=sumTime / counterPoints;
writeFile();
if (measureIndex >= maxNumberOfPointsStored - 1) {
// Reset the values of storedMeasures to the minimum value of the axis and also the sum of measurements
for (int i = 0; i < numberOfMeasurements; i++) {
for (int j = 0; j < maxNumberOfPointsStored; j++) {
storedMeasures[i][j] = 0;
}
}
for (int j = 0; j < maxNumberOfPointsStored; j++) {
storedTime[j] = 0;
}
measureIndex = 0; // Reset counter
// Serial.println("Reseting values measureIndex==0");
} else {
measureIndex++; // Increment counter
// Serial.println("increasing measureIndex");
}
for (int i = 0; i < numberOfMeasurements; i++) {
sumMeasures[i] = 0;
}
sumTime = 0;
counterPoints = 0;
// Serial.println("Reseting values counterPoints==0");
}
counterPoints += 1;
//wait enought for the sensor
if (currentMillis-previousTime<minTime) {
delay(minTime-(currentMillis-previousTime));
}
previousTime=currentMillis;
sumTime += currentMillis-initialTime;
for (int i = 0; i < numberOfMeasurements; i++) {
sumMeasures[i] += thermocouples[i].readCelsius();
}
}
the idea is that I can choose to write the data to an SD or printed in the serial monitor.
everything 'looks' okey, when I load the sketch to the arduino with printing the data in the monitor. I leaved the waiting time in case that the loop() goes too fast for the MAX that following its datasheet it has a response of 220 ms, (I leaved to a higher value of 500 ms as sometimes I was getting NAH when doing the request on the temperature)
okey up to here everything okey, I put my finger on the thermocouple the temperature increase I remove the finger and the temperature decrease, it looks like it works.
my issue comes when time passes..... after some minutes, the thermocouple temperatures measured they stabilize and at one point they do not change anymore... like I repeat of putting the finger on and off and the value does not change..... also while printing there are small variations of the temperature of , for example 0.1 °C between one and other measure over same thermocouple/max6675 but after a moment the temperature stays the same, like it does not change at all, always the same value (with exception of the time, as I am printing, time/temp1/temp2/temp3, so the buffer variable is being correctly updated.)
I have checked and re checked my sketch without finding any problem with it.
I would appreciate if anyone has an insight over this, if it is a hardware/software problem:
- the 5V of the arduino does not have enough power for 3 MAX6675?
- the MAX6675 and thermocouples are some cheap ones from amazon, maybe this could be an issue?
- my knowledge in C++ is as rudimentary as it can... so maybe is something in my code?
any insight would be appreciated
