Hello,
I am a newby with the esp32 and to make at first a speedtest. I write with the arduino ide:
digitalWrite(0, HIGH);
digitalWrite(0, LOW);
I look the sqaresignal on an oscilloscopescreen and see that the lowcycle is three times longer as the highcycle and
the freqency is 300kHz.
Can someone tell why the cycles are diffrent and why the frequency is so slow?
Many thanks foe every answer
Hans
Well, digital write and digital read are functions. There are some code behind them. They are not a single assembler instruction, so they take a hundreds of processor ticks to execure. Thats why you see 300Khz and not 240Mhz.
For the difference in timing please make an experiment. Insert short delay, like delay(10); after each digitalWrite and check the timing again
If you just need a squarewave signal generation then ESP32 has a functions for that: ledcWriteTone
You could also show your code and say which ESP32 variant you are using.
Is your "low" setting immediately followed by the potentially cache-defeating looping instructions?
if you wrote
void loop() {
digitalWrite(0, HIGH);
digitalWrite(0, LOW);
}
then the assembly code that gets generated is
set the pin HIGH
set the pin LOW
go back to the main() function which called loop
check a few things
go back to the loop() again
and so the code does
go to the loop() (save context)
set the pin HIGH
set the pin LOW
go back to the main() function which called loop
check a few things
go to the loop() (save context)
set the pin HIGH
set the pin LOW
go back to the main() function which called loop
check a few things
go to the loop() (save context)
...
as you can see there is lots that happens in between LOW and HIGH whereas there is "nothing" happening between HIGH and LOW ➜ that would explain what you see.
1 Like
Try this in setup().
void setup () {
.
.
.
while ( true ) {
digitalWrite(0, HIGH);
digitalWrite(0, LOW);
}
}
you still have a branch at the end of the while whereas there is no instruction between the HIGH and LOW
it will be faster than the loop() — which does more — but it's also likely to fail because of the watchdog.
True. As suggested above a small delay in-between will most likely smooth that out.
In fact, more like:
- Save some stuff to stack
- Look up some stuff about pin and port numbers
- Check a whole bunch of things
- Then conditionally set a pin high
- Return from function
Probably 10-20 lines of assembler at least.
1 Like
Here is the complete Code:
void setup () {
pinMode(0, OUTPUT);
}
void loop () {
digitalWrite(0, HIGH);
digitalWrite(0, LOW);
}
The board is a ESP32_C3 Super Mini
What will be the code in assembler?
Thanks
Hans
No, not really... Don't forget the optimiser will come into play
the assembly generated on a UNO for
void setup () {
pinMode(13, OUTPUT);
}
void loop () {
digitalWrite(13, HIGH);
digitalWrite(13, LOW);
}
looks like this (for the loop part)
void loop () {
digitalWrite(13, HIGH);
2c4: 81 e0 ldi r24, 0x01 ; 1
2c6: 0e 94 70 00 call 0xe0 ; 0xe0 <digitalWrite.constprop.0>
digitalWrite(13, LOW);
2ca: 80 e0 ldi r24, 0x00 ; 0
2cc: 0e 94 70 00 call 0xe0 ; 0xe0 <digitalWrite.constprop.0>
2d0: 20 97 sbiw r28, 0x00 ; 0
2d2: c1 f3 breq .-16 ; 0x2c4 <main+0xc0>
you can actually see that the main() got optimized out as well as the explicit storage of the pin number as the optimizer inlined it directly within the digitalWrite implementation
the sbiw is fun to see (subtracting 0 won't do much but resets the zero flag ) so that breq .-16 will always happen.
so basically you have the same 2 lines for the digitalWrite — except for one the r24 register is loaded with 1 (HIGH) and 0 (LOW) for the other
the difference in pulse rate will come from the 2 instructions sbiw and breq
3 Likes
The code may be strongly entangled with the RTOS run time system and not really recognisable as a stand alone entity.
1 Like
I found digitalReadFast and digitalWriteFast. Is this also available for a ESP32?
You should say what you are trying to do and what waveform (frequency, dutycycle etc.) you are expecting to appear on a digital pin. There is almost certainly a better way that simply using digitalWrite() to achieve it.
One suggestion appears in post #2.
Oh! A RISC-V variant!
What will be the code in assembler?
Ugh. extracted from 4MB of slowly generated RISC-V code:
(assorted pithy comments noted with ";;")
;; main task...
for (;;) {
if (loopTaskWDTEnabled) {
esp_task_wdt_reset();
}
loop();
if (serialEventRun) {
42000c1e: 42001437 lui s0,0x42001
if (loopTaskWDTEnabled) {
42000c22: 3fc8f4b7 lui s1,0x3fc8f
if (serialEventRun) {
42000c26: 00c40413 addi s0,s0,12 # 4200100c <serialEventRun()>
yieldIfNecessary();
42000c2a: 3fa5 jal 42000ba2 <yieldIfNecessary()>
if (loopTaskWDTEnabled) {
42000c2c: 9384c783 lbu a5,-1736(s1) # 3fc8e938 <loopTaskWDTEnabled>
42000c30: c399 beqz a5,42000c36 <loopTask(void*)+0x46>
esp_task_wdt_reset();
42000c32: 2ac080ef jal ra,42008ede <esp_task_wdt_reset>
loop();
42000c36: bf0ff0ef jal ra,42000026 <loop()>
if (serialEventRun) {
42000c3a: d865 beqz s0,42000c2a <loopTask(void*)+0x3a>
serialEventRun();
42000c3c: 2ec1 jal 4200100c <serialEventRun()>
42000c3e: b7f5 j 42000c2a <loopTask(void*)+0x3a>
}
}
;; loop(), itself...
42000026 <loop()>:
42000026: 1141 addi sp,sp,-16
42000028: 4585 li a1,1
4200002a: 4505 li a0,1
4200002c: c606 sw ra,12(sp)
4200002e: 28c1 jal 420000fe <__digitalWrite>
42000030: 40b2 lw ra,12(sp)
42000032: 4581 li a1,0
42000034: 4505 li a0,1
42000036: 0141 addi sp,sp,16
42000038: a0d9 j 420000fe <__digitalWrite>
;; digitalWrite()
420000fe <__digitalWrite>:
extern void ARDUINO_ISR_ATTR __digitalWrite(uint8_t pin, uint8_t val) {
420000fe: 1141 addi sp,sp,-16
42000100: c422 sw s0,8(sp)
42000102: c606 sw ra,12(sp)
42000104: c226 sw s1,4(sp)
#ifdef RGB_BUILTIN
;; Oh! Special code to make a neopixel behave like a normal LED!
if (pin == RGB_BUILTIN) {
42000106: 47f9 li a5,30
extern void ARDUINO_ISR_ATTR __digitalWrite(uint8_t pin, uint8_t val) {
42000108: 842e mv s0,a1
if (pin == RGB_BUILTIN) {
4200010a: 02f51063 bne a0,a5,4200012a <__digitalWrite+0x2c>
if (perimanGetPinBus(pin, ESP32_BUS_TYPE_GPIO) != NULL) {
gpio_set_level((gpio_num_t)pin, val);
} else {
log_e("IO %i is not set as GPIO.", pin);
}
}
4200010e: 4422 lw s0,8(sp)
42000110: 40b2 lw ra,12(sp)
42000112: 4492 lw s1,4(sp)
const uint8_t comm_val = val != 0 ? RGB_BRIGHTNESS : 0;
42000114: 00b036b3 snez a3,a1
RGB_BUILTIN_storage = val;
42000118: 3fc8f7b7 lui a5,0x3fc8f
4200011c: 92b789a3 sb a1,-1741(a5) # 3fc8e933 <RGB_BUILTIN_storage>
const uint8_t comm_val = val != 0 ? RGB_BRIGHTNESS : 0;
42000120: 069a slli a3,a3,0x6
neopixelWrite(RGB_BUILTIN, comm_val, comm_val, comm_val);
42000122: 8636 mv a2,a3
42000124: 85b6 mv a1,a3
}
42000126: 0141 addi sp,sp,16
neopixelWrite(RGB_BUILTIN, comm_val, comm_val, comm_val);
42000128: a38d j 4200068a <neopixelWrite>
if (perimanGetPinBus(pin, ESP32_BUS_TYPE_GPIO) != NULL) {
4200012a: 4585 li a1,1
4200012c: 84aa mv s1,a0
4200012e: 2655 jal 420004d2 <perimanGetPinBus>
42000130: c909 beqz a0,42000142 <__digitalWrite+0x44>
gpio_set_level((gpio_num_t)pin, val);
42000132: 85a2 mv a1,s0
}
42000134: 4422 lw s0,8(sp)
42000136: 40b2 lw ra,12(sp)
gpio_set_level((gpio_num_t)pin, val);
42000138: 8526 mv a0,s1
}
4200013a: 4492 lw s1,4(sp)
4200013c: 0141 addi sp,sp,16
gpio_set_level((gpio_num_t)pin, val);
4200013e: 3ca0306f j 42003508 <gpio_set_level>
}
;; gpio_set_level (wow, that's a lot of code for the bottom level function!!)
(Ok, it's not "bottom level" in the source. There are a chain of inline functions...)
42003508 <gpio_set_level>:
42003508: 1141 addi sp,sp,-16
4200350a: c606 sw ra,12(sp)
4200350c: c422 sw s0,8(sp)
4200350e: c226 sw s1,4(sp)
42003510: 00054f63 bltz a0,4200352e <gpio_set_level+0x26>
42003514: 862a mv a2,a0
42003516: 842a mv s0,a0
42003518: 00400537 lui a0,0x400
4200351c: 84ae mv s1,a1
4200351e: 157d addi a0,a0,-1 # 3fffff <_esp_mmu_block_size+0x3effff>
42003520: 4581 li a1,0
42003522: fdffd097 auipc ra,0xfdffd
42003526: 30e080e7 jalr 782(ra) # 40000830 <__lshrdi3>
4200352a: 8905 andi a0,a0,1
4200352c: e521 bnez a0,42003574 <gpio_set_level+0x6c>
4200352e: fe387097 auipc ra,0xfe387
42003532: ee2080e7 jalr -286(ra) # 4038a410 <esp_log_timestamp> ;;; Really??
42003536: 3c0315b7 lui a1,0x3c031 ;; Eww!
4200353a: 3c0318b7 lui a7,0x3c031 ;; doesn't
4200353e: 3c0317b7 lui a5,0x3c031 ;; seem
42003542: 3c031637 lui a2,0x3c031 ;; efficient!
42003546: 86aa mv a3,a0
42003548: f4858713 addi a4,a1,-184 # 3c030f48 <__func__.6+0x28>
4200354c: 4505 li a0,1
4200354e: f6888893 addi a7,a7,-152 # 3c030f68 <__func__.6+0x48>
42003552: 0ee00813 li a6,238
42003556: 1b078793 addi a5,a5,432 # 3c0311b0 <__FUNCTION__.35>
4200355a: f5060613 addi a2,a2,-176 # 3c030f50 <__func__.6+0x30>
4200355e: f4858593 addi a1,a1,-184
42003562: 1a9100ef jal ra,42013f0a <__wrap_esp_log_write>
42003566: 10200513 li a0,258
4200356a: 40b2 lw ra,12(sp)
4200356c: 4422 lw s0,8(sp)
4200356e: 4492 lw s1,4(sp)
42003570: 0141 addi sp,sp,16
42003572: 8082 ret
42003574: 8a81a783 lw a5,-1880(gp) # 3fc8bca8 <gpio_context>
42003578: 4398 lw a4,0(a5)
4200357a: 04000793 li a5,64
4200357e: 00879533 sll a0,a5,s0
42003582: 8119 srli a0,a0,0x6
42003584: c889 beqz s1,42003596 <gpio_set_level+0x8e>
42003586: 471c lw a5,8(a4)
42003588: fc0006b7 lui a3,0xfc000
4200358c: 8ff5 and a5,a5,a3
4200358e: 8fc9 or a5,a5,a0
42003590: c71c sw a5,8(a4)
42003592: 4501 li a0,0
42003594: bfd9 j 4200356a <gpio_set_level+0x62>
42003596: 475c lw a5,12(a4)
42003598: fc0006b7 lui a3,0xfc000
4200359c: 8ff5 and a5,a5,a3
4200359e: 8fc9 or a5,a5,a0
420035a0: c75c sw a5,12(a4)
420035a2: bfc5 j 42003592 <gpio_set_level+0x8a>
Suffice to say that it could all be done much faster, if anyone cared very much...
2 Likes
Hello,
my goal is not to generate a waveform. I'm just looking for a way to make setting and reading I/Os faster so that a program runs faster.
Don't use digitalWrite/Read; use PWM instead.
1 Like
A bit too late too reply but may be it will help others:
On a basic ESP32 one can reach 16Mhz speed. On ESP32S3 it is up to 80Mhz but is a different story.
Code below switches pin 2 at approximately 16 Mhz. I measured it. It takes 12 CPU cycles to toggle a pin. Hopefully this helps. Code works on any ESP32.
To reach 80Mhz rate on ESP32S3 you have to read about "dedicated GPIO"
#include <Arduino.h>
#include <hal/gpio_ll.h> // gpio_ll_ functions
#include <soc/gpio_struct.h> // GPIO global variable
#define LED 2
void setup() {
Serial.begin(115200);
pinMode(LED,OUTPUT);
}
void loop() {
while( 1 ) {
gpio_ll_set_level(&GPIO,2,0); // digitalWrite(2,LOW)
gpio_ll_set_level(&GPIO,2,1); // digitaelWrite(2.HIGH)
}
}There also faster versions of digitalRead() as well
Are we talking ESP32 (tensilica xtensa CPU) or ESP32C (RISC-V CPU)?
On ESP32:
hw->out_w1tc = (1 << gpio_num);
400d1674: 0020c0 memw
400d1677: 3899 s32i.n a9, a8, 12
hw->out_w1ts = (1 << gpio_num);
400d1679: 0020c0 memw
400d167c: 2899 s32i.n a9, a8, 8
400d167e: fffc86 j 400d1674 <loop()+0x8>
On ESP32C:
hw->out_w1tc.out_w1tc = (1 << gpio_num);
42000062: 47d8 lw a4,12(a5)
42000064: 8f75 and a4,a4,a3
42000066: 00476713 ori a4,a4,4
4200006a: c7d8 sw a4,12(a5)
hw->out_w1ts.out_w1ts = (1 << gpio_num);
4200006c: 4798 lw a4,8(a5)
4200006e: 8f75 and a4,a4,a3
42000070: 00476713 ori a4,a4,4
42000074: c798 sw a4,8(a5)
42000076: b7f5 j 42000062 <loop()+0xc>
(which is ... weird. The .h file apparently defines out_w1ts as a struct with "reserved" bits, which forces the compiler to do the whole read/modify/write sequence (rather defeating the purpose of having SET and CLEAR registers!)
union {
struct {
uint32_t out_w1tc: 26;
uint32_t reserved26: 6;
};
uint32_t val;
} out_w1tc;
this sort of "non-existent pins are "reserved" rather than just "ignored" is ... uncommon.)
In both cases, it would probably get somewhat faster if the function is moved into RAM.
I have submitted an "issue" for Espressif to consider.
1 Like
