New to the forum and can use some help with my home brew project for a garage door with sensor.
My code using FauxmoESP works (Alexa discover devices, turns on / off, etc.). I would like to include wifi provisioning to eliminate the hard coding of an SSSID, and password with the use of the WifiManager. I can make them work independently of each other, but not together in my implementation. If I include the WifiManager, then my devices are no longer discoverable by Alexa.
I must be missing something, and could use some help. Thanks in advance.
Board: NodeMCU 1.0 (ESP-12E Module)
IwIP Variant: v1.4 Higher Bandwidth
FauxmoESP: 3.1.0
WifiManager: 0.14.0
#include <ESP8266WiFi.h>
#include <DNSServer.h>
#include <ESP8266WebServer.h>
#include <WiFiManager.h> //https://github.com/tzapu/WiFiManager
#include "fauxmoESP.h"
String wifiSSID;
String wifiPassword;
fauxmoESP fauxmo;
#define SERIAL_BAUDRATE 115200
typedef struct _device {
String sName;
uint8_t relayPin;
uint8_t relayMode;
unsigned long relayMillis;
uint8_t sensorPin;
uint8_t sensorMode;
} Device;
#define NUM_DEVICES 2
Device devices[NUM_DEVICES] = { {.sName = "Denice's Garage Door", .relayPin = D5, .relayMode = OUTPUT, .relayMillis = millis(), .sensorPin = D1, .sensorMode = INPUT_PULLUP},
{.sName = "Kitchen Garage Door", .relayPin = D6, .relayMode = OUTPUT, .relayMillis = millis(), .sensorPin = D2, .sensorMode = INPUT_PULLUP}
};
/* D1 5 GPI05 INPUT_PULLUP
* D2 4 GPI04 INPUT_PULLUP
* D5 14 GPI014 OUTPUT
* D6 12 GPI12 OUTPUT
*
* LOW ON OUTPUT PIN CONTINUITY ACROSS NORMALLY CLOSED AND COMMON
* HIGH ON OUTPUT PIN CONTINUITY ACROSS NORMALLY OPEN AND COMMON
*/
const char* getPinNumber (uint8_t pin) {
switch (pin) {
case 4:
return("D2");
case 5:
return("D1");
case 14:
return("D5");
case 12:
return("D6");
default:
return("ERROR");
}
}
const char* getPinMode (uint8_t pin) {
switch (pin) {
case INPUT:
return("INPUT");
case INPUT_PULLUP:
return("INPUT_PULLUP");
case OUTPUT:
return("OUTPUT");
default:
return("ERROR");
}
}
void dumpDevices () {
for (int cCnt = 0; cCnt < (sizeof devices / sizeof devices[0]); cCnt++) {
Serial.printf("[dumpDevices] .sName[%s], .relayPin[%s], .relayMode[%s], .relayState[%s], .relayMillis[%lu], .sensorPin[%s%], .sensorMode[%s], .sensorState[%s]\n",
devices[cCnt].sName.c_str(),
getPinNumber(devices[cCnt].relayPin),
getPinMode(devices[cCnt].relayMode),
digitalRead(devices[cCnt].relayPin) ? "HIGH" : "LOW",
devices[cCnt].relayMillis,
getPinNumber(devices[cCnt].sensorPin),
getPinMode(devices[cCnt].sensorMode),
digitalRead(devices[cCnt].sensorPin) ? "HIGH" : "LOW");
}
}
void onSetStateDevices(const char * device_name, bool state) {
// Alexa ON = OPEN = LOW
// Alexa OFF = CLOSE = HIGH
// connect Device sensors and relays
for (int cCnt = 0; cCnt < (sizeof devices / sizeof devices[0]); cCnt++) {
if (strcmp(device_name, devices[cCnt].sName.c_str()) == 0) {
// close the garage if it is open
if (state == LOW) {
// only close the Device if it is open
if (digitalRead(devices[cCnt].sensorPin) == HIGH) {
Serial.printf("[onSetStateDevices] Closed: %s\n", devices[cCnt].sName.c_str());
digitalWrite(devices[cCnt].relayPin, LOW);
devices[cCnt].relayMillis = millis();
}
}
// open the garage if it is closed
else {
// only open the Device if it is closed
if (digitalRead(devices[cCnt].sensorPin) == LOW) {
Serial.printf("[onSetStateDevices] Open: %s\n", devices[cCnt].sName.c_str());
digitalWrite(devices[cCnt].relayPin, LOW);
devices[cCnt].relayMillis = millis();
}
}
return;
}
}
}
void setupDevices () {
Serial.println("[setupDevices]");
// connect Device sensors and relays
for (int cCnt = 0; cCnt < (sizeof devices / sizeof devices[0]); cCnt++) {
pinMode(devices[cCnt].relayPin, devices[cCnt].relayMode);
digitalWrite(devices[cCnt].relayPin, HIGH); // don't do anything on startup
pinMode(devices[cCnt].sensorPin, devices[cCnt].sensorMode);
fauxmo.addDevice(devices[cCnt].sName.c_str());
}
dumpDevices();
}
void setupWifiConfig () {
//WiFiManager
//Local intialization. Once its business is done, there is no need to keep it around
WiFiManager wifiManager;
//reset settings - for testing
//wifiManager.resetSettings();
//sets timeout until configuration portal gets turned off
//useful to make it all retry or go to sleep
//in seconds
//wifiManager.setTimeout(120);
//it starts an access point with the specified name
//here "AutoConnectAP"
//and goes into a blocking loop awaiting configuration
//WITHOUT THIS THE AP DOES NOT SEEM TO WORK PROPERLY WITH SDK 1.5 , update to at least 1.5.1
//WiFi.mode(WIFI_STA);
if (!wifiManager.startConfigPortal("myGarage", "linkster")) {
Serial.println("failed to connect and hit timeout");
delay(3000);
//reset and try again, or maybe put it to deep sleep
ESP.reset();
delay(5000);
}
//if you get here you have connected to the WiFi
Serial.println("connected...yeey :)");
wifiSSID = WiFi.SSID();
wifiPassword = WiFi.psk();
Serial.printf("[setupWifiConfig] wifiSSID[%s]\n", wifiSSID.c_str());
Serial.printf("[setupWifiConfig] wifiPassword[%s]\n", wifiPassword.c_str());
}
void wifiSetup() {
Serial.println("[wifiSetup]");
// Set WIFI module to STA mode
WiFi.mode(WIFI_STA);
// Connect
Serial.printf("[WIFI] Connecting to %s ", wifiSSID.c_str());
WiFi.begin(wifiSSID, wifiPassword);
// Wait
while (WiFi.status() != WL_CONNECTED) {
Serial.print(".");
delay(100);
}
Serial.println();
// Connected!
Serial.printf("[WIFI] STATION Mode, SSID: %s, IP address: %s\n", WiFi.SSID().c_str(), WiFi.localIP().toString().c_str());
}
void setup() {
// Init serial port and clean garbage
Serial.begin(SERIAL_BAUDRATE);
Serial.println();
Serial.println();
Serial.println("[setup]");
// get wifi ssid and password
setupWifiConfig();
// Wifi
wifiSetup();
fauxmo.createServer(true); // not needed, this is the default value
fauxmo.setPort(80); // This is required for gen3 devices
fauxmo.enable(true);
setupDevices();
fauxmo.onSetState([](unsigned char device_id, const char * device_name, bool state, unsigned char value) {
Serial.printf("[MAIN] Device #%d (%s) state: %s value: %d\n", device_id, device_name, state ? "ON" : "OFF", value);
onSetStateDevices(device_name, state);
});
}
void loop() {
fauxmo.handle();
for (int cCnt = 0; cCnt < (sizeof devices / sizeof devices[0]); cCnt++) {
if (digitalRead(devices[cCnt].relayPin) == LOW) {
if (millis() - devices[cCnt].relayMillis > 2000) {
devices[cCnt].relayMillis = millis();
digitalWrite(devices[cCnt].relayPin, HIGH);
Serial.printf("[loop] Reset %s %s[HIGH]\n", devices[cCnt].sName.c_str(), getPinNumber(devices[cCnt].relayPin));
}
}
}
// fauxmo.setState(ID_YELLOW, true, 255);
}
myGarage_2.0.ino (10.1 KB)
